Kintowe composite material guide rings have a rectangular cross-section and are chamfered at the corners to avoid excess edge pressures at groove corners. The chamfers also serve to simplify assembly.

Send Inquiry

Description

Meanwhile, our firm staffs a group of experts devoted to your development of Phenolic Resin and Polyester Resin Composite Pipes, Composite Spherical Bearings, Composite Thrust Bearings. We will always carry forward the entrepreneurial spirit of hard work, self-improvement, keeping pace with the times and innovation, and earnestly fulfill the business philosophy of integrity-based and win-win harmony. We hope that every employee will agree with the value concept of the company and take the company's strategic goals and personal job targets as the action platform.

The guide rings are made of a new composite material which avoids metal-to-metal contact between moving parts in a working hydraulic cylinder. Compared to metal guides, they have following advantages:

Cost-effective

Easy assembly in closed grooves

Significantly longer service life

High resistance to insufficient lubrication at low speeds

Load more evenly and reduces stress to the counter surface

Product parameter

Color	Light yellow to brown
Material	Phenolic resin reinforced with synthetic fiber(PFC-6)
Density	1.2-1.4g/cm³	0.043-0.051lb/in³
Tensile Strength	40MPa	5800PSI
Ultimate Compressive Strength	320MPa	46400PSI
Impact Strength	215 J/m
Rockwell Hardness	80HRM
Coefficient of friction	0.20-0.40(Dry) 0.09-0.12(Oil)
Temperature	-40° to 130° C	-104° F to 266° F

Product application

Kintowe composite guide rings are suitable for engineering machineries hydraulic cylinders, like Excavators, Loaders, Dozzers, Cranes, Forklifts.

NeoImage_

Product details

Machining Tolerances

Height: 0/-0.30

Thickness: 0/-0.05

Outer diameter(OD): ±0.1

Inner diameter(ID): ±0.1

Cut gap could be in angle cut, butt cut, step cut

Outer diameter（OD）	≤100	100＜OD＜200	200≤OD＜400	400≤OD＜600
Cut gap	2	3	4	5
Limit deviation	±1	±1	±1	±1

Product Qualification

Piston guide rings

OD x ID x H	OD x ID x H	OD x ID x H	OD x ID x H
16 x 11 x 5.6	50 x 45 x 5.6	75 x 70 x 5.6	120 x 114 x 13
16 x 12.9 x 4	50 x 45 x 6.3	75 x 70 x 9.7	120 x 114 x 20
	50 x 45 x 9.7		120 x 114 x 30
18 x 13 x 5.6	50 x 46 x 12	80 x 72 x 12	120 x 114 x 40
18 x 14.9 x 4	50 x 46.9 x 4	80 x 74 x 13	120 x 115 x 9.7
		80 x 74 x 20
20 x 15 x 5.6	55 x 50 x 4	80 x 74 x 25	125 x 119 x 13
20 x 16.9 x 4	55 x 50 x 5.6		125 x 119 x 15
	55 x 50 x 9.7	80 x 75 x 5.6	125 x 119 x 20
25 x 20 x 5.6	55 x 50 x 25	80 x 75 x 9.7	125 x 119 x25
25 x 21.9 x 4		80 x 75 x 15	125 x 119 x 30
	60 x 54 x 10		125 x 120 x 9.7
30 x 24 x 10	60 x 54 x 13	85 x 79 x 30
30 x 25 x 5.6	60 x 54 x 20	85 x 80 x 5.6	130 x 124 x 13
30 x 26.9 x 4	60 x 54 x 30	85 x 80 x 9.7	130 x 124 x 30
			130 x 125 x 9.7
32 x 27 x 5.6	60 x 55 x 5.6	90 x 84 x 13
32 x 28.9 x 4	60 x 55 x 6.3	90 x 84 x 20	135 x 129 x 13
	60 x 55 x 9.7	90 x 85 x 5.6
35 x 30 x 5.6		90 x 85 x 9.7	140 x 134 x 13
35 x 31.9 x 4	63 x 57 x 13		140 x 134 x 20
	63 x 57 x 20	95 x 89 x 13	140 x 134 x 25
40 x 34 x 10	63 x 58 x 5.6	95 x 90 x 9.7	140 x 134 x 30
40 x 35 x 5.6	63 x 58 x 6.3		140 x 135 x 9.7
40 x 35 x 9.7	63 x 58 x 9.7	100 x 94 x 13	140 x 135 x 15
40 x 36 x 10	63 x 58 x 10	100 x 94 x 20
40 x 36.9 x 4		100 x 94 x 25	145 x 139 x 30
	65 x 59 x 13	100 x 94 x 30
45 x 39 x 10	65 x 59 x 20	100 x 95 x 9.7	150 x 144 x 13
45 x 40 x 5.6	65 x 60 x 5.6		150 x 144 x 20
45 x 41 x 12	65 x 60 x 9.7	110 x 104 x 13	150 x 144 x 30
45 x 41.9 x 4		110 x 104 x 20	150 x 144 x 40
	70 x 64 x 13	110 x 104 x 30	150 x 145 x 9.7
50 x 44 x 10	70 x 64 x 20	110 x 105 x 9.7	150 x 145 x 15
	70 x 65 x 5.6	110 x 105 x 15
	70 x 65 x 9.7		155 x 149 x 13
	70 x 65 x 20	115 x 109 x 13
		115 x 110 x 9.7
OD x ID x H	OD x ID x H	OD x ID x H
160 x 154 x 13	210 x 205 x 9.7	300 x 292 x 20
160 x 154 x 15	210 x 205 x 15	300 x 292 x 25
160 x 154 x 19.5		300 x 292 x 40
160 x 154 x 30	220 x 212 x 20	300 x 295 x 15
160 x 154 x 35	220 x 212 x 30	300 x 295 x 25
160 x 154 x 50	220 x 214 x 19.5
	220 x 214 x 30	400 x 392 x 30
160 x 155 x 9.7	220 x 215 x 9.7
160 x 155 x 15	220 x 215 x 15

170 x 160 x 20	230 x 225 x 15
170 x 164 x 19.5
170 x 164 x 20	240 x 232 x 25
170 x 164 x 30	240 x 232 x 40
170 x 165 x 9.7	240 x 235 x 9.7
170 x 165 x 15	240 x 235 x 15

180 x 172 x 40	250 x 242 x 20
180 x 174 x 13	250 x 242 x 25
180 x 174 x 19.5	250 x 242 x 40
180 x 174 x 30	250 x 244 x 19.5
180 x 175 x 9.7	250 x 244 x 50
180 x 175 x 15
	250 x 245 x 9.7
190 x 184 x 25	250 x 245 x 15
190 x 184 x 30
190 x 185 x 9.7	260 x 255 x 9.7
190 x 185 x 15	260 x 255 x 15

200 x 192 x 25	270 x 262 x 25
200 x 194 x 20	270 x 262 x 30
200 x 194 x 30
200 x 194 x 50	280 x 272 x 25
	280 x 275 x 15
200 x 195 x 9.7	280 x 275 x 25
200 x 195 x 15
200 x 195 x 20

Rod guide rings

ID x OD x H	ID x OD x H	ID x OD x H	ID x OD x H
12 x 15 x 6.3	30 x 33.1 x 4	45 x 49 x 15	65 x 70 x 9.7
12 x 15.1 x4	30 x 34 x 10	45 x 50 x 5.6	65 x 71 x 13
	30 x 35 x 5.6	45 x 50 x 9.7	65 x 71 x 20
14 x 17.1 x 4		45 x 51 x 13	65 x 71 x 40
	32 x 35 x 5.6	45 x 51 x 20
15 x 18.1 x 4	32 x 35.1 x 4.2	45 x 51 x 40	70 x 75 x 9.7
	32 x 36 x 10		70 x 76 x 13
16 x 19 x 6	32 x 36 x 15	50 x 55 x 5.6	70 x 76 x 20
16 x 19.1 x 4	32 x 36 x 20	50 x 55 x 9.7	70 x 76 x 30
16 x 20 x 10		50 x 55 x 15	70 x 76 x 40
	32 x 37 x 5.6	50 x 56 x 13	70 x 76 x 50
18 x 21.1 x 4	32 x 37 x 9.7	50 x 56 x 20
	32 x 38 x 10	50 x 56 x 30	75 x 80 x 9.7
20 x 23 x 10			75 x 81 x 13
20 x 23.1 x4	35 x 38 x 10	55 x 60 x 5.6	75 x 81 x 20
20 x 24 x 5.6	35 x 39 x 20	55 x 60 x 9.7	75 x 81 x 30
	35 x 40 x 5.6		75 x 81 x 60
22 x 25 x 10	35 x 40 x 9.7	56 x 61 x 5.6
22 x 25.1 x 4	35 x 41 x 10	56 x 61 x 9.7	80 x 85 x 9.7
		56 x 62 x 13	80 x 85 x 15
25 x 28 x 6	36 x 40 x 10	56 x 62 x 16	80 x 86 x 13
25 x 28 x 10	36 x 40 x 30	56 x 62 x 30	80 x 86 x 20
25 x 28 x 20	36 x 41 x 5.6	56 x 62 x 40
25 x 28.1 x 4	36 x 41 x 9.7		80 x 86 x 25
25 x 28.1 x 4.2	36 x 42 x 10	60 x 65 x 5.6	80 x 86 x 30
		60 x 65 x 9.7	80 x 86 x 40
25 x 29 x 5.6	40 x 43 x 5.6	60 x 65 x 15	80 x 86 x 50
25 x 29 x 10	40 x 44 x 10	60 x 66 x 13
25 x 29 x 20	40 x 44 x 20	60 x 66 x 20	85 x 90 x 9.7
25 x 30 x 5.6	40 x 44 x 25	60 x 66 x 30	85 x 90 x 15
25 x 31 x 10	40 x 45 x5.6		85 x 91 x 13
	40 x 45 x 9.7	63 x 68 x 5.6	85 x 91 x 20
28 x 31.1 x 4		63 x 68 x 9.7	85 x 91 x 25
28 x 32 x 10	40 x 46 x 10	63 x 68 x 15
28 x 33 x 5.6	40 x 46 x 15	63 x 69 x 13
28 x 34 x 10	40 x 46 x 20	63 x 69 x 20
	40 x 46 x 25	63 x 69 x 30

ID x OD x H	ID x OD x H	ID x OD x H
90 x 95 x 9.7	125 x 131 x 13	180 x 185 x 9.7
90 x 95 x 15	125 x 131 x 30	180 x 185 x 15
90 x 96 x 13	125 x 131 x 40	180 x 186 x 19.5
90 x 96 x 20	125 x 131 x 50
90 x 96 x 30		195 x 203 x 25
90 x 96 x 40	125 x 133 x 20
	125 x 133 x 30	200 x 205 x 15
95 x 100 x 9.7	125 x 133 x 45	200 x 205 x 25
95 x 100 x 15	125 x 133 x 60
		220 x 218 x 25
100 x 105 x 9.7	127 x 133 x 13
100 x 105 x 15		220 x 225 x 15
	130 x 135 x 9.7	220 x 225 x 25
100 x 106 x 13	130 x 135 x 15	220 x 228 x 25
100 x 106 x 20
100 x 106 x 25	135 x 141 x 90	235 x 243 x 30
100 x 106 x 30
100 x 106 x 40	140 x 145 x 9.7	250 x 255 x 15
100 x 106 x 50	140 x 145 x 15	250 x 255 x 25

105 x 111 x 20	140 x 146 x 13	255 x 263 x 25
	140 x 146 x 20
110 x 115 x 9.7	140 x 146 x 25	264 x 272 x 24
110 x 115 x 15	140 x 146 x 40
110 x 116 x 13	140 x148 x 20	305 x 313 x 25
110 x 116 x 20
110 x 116 x 30	150 x 155 x 9.7	365 x 373 x 35
	150 x 155 x 15
115 x 121 x 20	150 x 156 x 19.5
	150 x 156 x 30
120 x 125 x 9.7	150 x 158 x 20
120 x 125 x 15
120 x 126 x 40	160 x 165 x 9.7
120 x 126 x 50	160 x 165 x 15
	160 x 166 x 30
125 x 130 x 9.7	160 x 168 x 30
125 x 130 x 15	160 x 168 x 40
